Equipment: Tipper Walls and bottom in high abrasion resistance steel. Hardness: HB 400, Capacity Struck 20cm Heaped (SAE 2:1) 25,2cm
Quantity Available on Stock: 5
Price: 356.250,00 EURO
Colour: White / Red
Cabin: Complying with ROPS ISO 3471 and FOPS ISO3449 level II. In steel, sound-proof and installed on the left side
Engine / Cylinders: Iveco Cursor 13 / 6 Cylinders - Direct electronic injection, pump injectors, turbo charger with intercooler, VGT
Power: 368 kW (500 HP)
Emission: TIER III
Drive: 4x2
Axles: Rear KESSLER axle. Double reduction: central by bevel gear pair and final in wheel hubs by epicyclic train.
Brakes F/R: Pneumo-hydraulic controlled dry disc with 2 independent circuits, one for each axle - Hydraulic retarder: between torque converter and gearbox
Gearbox: Automatic transmission Allison H5610AR with 6 forward speeds and 2 reverse. Hydraulic torque converter
Dimension: G.V.W. 70.000 kg and Payload 40.000 kg; 4.110 mm x 7.864mm x 4.127mm
Suspension F/R: Front: independent steering wheels, hydro-pneumatic suspension cylinders (oil-nitrogen) acting as suspension/shock absorber. Rear: semi-independent with A-frame and Panhard type cross bar. Two hydro-pneumatic cylinders (oil/nitrogen) acting as suspension/shock absorber.
