Equipment: Tipper Walls and bottom in high abrasion resistance steel. Hardness: HB 400, Capacity Struck 16cm Heaped (SAE 2:1) 20,5cm
Quantity Available on Stock: 6
Price: 225.000,00 EURO
Colour: White / Red
Cabin: Complying with ROPS ISO 3471 and FOPS ISO3449 level II. In steel, sound-proof and installed on the left side
Engine / Cylinders: Diesel cycle with 6 cylinders in line, direct electronic injection, pump injectors, turbo charger with intercooler, variable geometry turbine
Power: 280kW (381 hp)
Emission: TIER 3
Drive: 4x2
Axles: Rear KESSLER axle. Double reduction: central by crown wheel and pinion and final in wheel hubs by epicyclical gearing.
Brakes F/R: Independent circuits, in compliance with ISO 3450. Disk brakes with two callipers for axle. Hydraulic control with engine controlled gear pump and two pressure accumulators
Gearbox: Automatic transmission Allison HD4560 with integrated retarder on gear output. 6 forward speeds and one reverse
Dimension: 7355mm x 3806mm x 3700mm
Suspension F/R: Front: independent steering wheels, hydro-pneumatic suspension cylinders (oil-nitrogen) acting as suspension/shock absorber. Rear: semi-independent with three reaction rods and Panhard type cross bar. Two hydro-pneumatic cylinders (oil/nitrogen) acting as suspension/shock absorber
