Product Details
- Model:
- ADT40 D
- Year of Registration:
- 2014
- Equipment:
- Tipper Walls and bottom in high abrasion strength steel (Hardox 400) - Payload 36.000 kg (40 Sht) - Body heaped (SAE 2:1) 22 m 3
- Quantity Available on Stock:
- 1
- Price:
- 331.250,00 EURO
- Colour:
- White / Red
- Cabin:
- ROPS ISO 3471 / FOPS ISO 3449 Level II Stainless steel, soundproof and centrally installed, suspended through oil-rubber pads
- Engine / Cylinders:
- IVECO CURSOR 13 / 6 Cylinders - Diesel cycle, electronically-controlled direct injection, pump injectors, VGT with intercooler.
- Power:
- 335 KW ( 455 HP) @ 2100 rpm
- Emission:
- TIER III
- Drive:
- Permanent 6x6 drive configuration
- Axles:
- 2 nd and 3 axle ZF MT - Double reduction: central by bevel gear and final by planetary gears in wheel hubs. Lockable rear interaxle
- Brakes F/R:
- Oil-cooled wet multiple disc brakes, with engine powered gear pump and with two pressure accumulators
- Gearbox:
- Automatic ERGOPOWER ZF 6WG 310 transmission with 6 gears forward and 3 reverse. Hydraulic torque converter
- Dimension:
- TOTAL WEIGHT (G.V.W.) 65.000kg - 10.782mm x 3.465mm
- Suspension F/R:
- Front: semi-independent, with “A” frame and PANHARD crossbar Hydro-pneumatic suspension cylinders (oil-nitrogen). Rear: semi-independent rocker type, connected to axles by flexible joints and integrated with central reaction bars on axles.
- Tyres F/R:
- Tubeless 29,5R25 tyres
